HPM 5 KVA LPG Generator Petrol & LPG RUN, Recoil & Self Start

Specification :

Model NameGE-5000 RS-LPG

Generator

• Max AC. Output VA : 4500
• Rated AC. Output VA : 4000
• Rated Current Amps : 17
• NFB Amps : 18
• AC. Voltage at Rated Load : 220 Volts ± 10 Volt50 Hz, Single Phase
• AC. Voltage at No Load : 250 Volts ± 5 Volt

Alternator

• Alternator Max. Current Capacity : 24 Amps
• Alternator : Brushless, Rare Earth Magnetic Rotor, THD 5 %, Pure Sine Wave

Engine

• Model : HM170 P
• Type : OHV25°Inclined,Single Cylinder,4 Strokes, S.I, Forced Air Cooling
• Maximum Power : 7.5 HP @ 3600
• Bore x Stroke : 70x58 mm
• Displacement : 223cc
• Starting System :Recoil Start and Self Start+Remote Start
• Fuel : Petrol + LPG
• Fuel Tank Capacity : Petrol - 12.0 Ltr
• Fuel Consumption : Petrol: 1.5 Ltr./hr.,  LPG: 800 gram ./hr. Approx
• Continues Running (With One Filling) : Approx. 8 Hrs. on Petrolor< 20 hours Per LPG Cylinder
• Lube. Oil Capacity : 600 ml
• Lubricating Oil Consumption : 2.5 gm./Hr
• Sound level (Db) (from 1 meter)<86Db

Panel &Other Standard Features

• Voltmeter : Yes (Analogue)
• Digital Hour Meter : No
• Oil Alert System : Yes
• LPG/ Gas Fuel Compatibility : Yes
• Overload Protection (NFB) : Yes

Size & Weight

• Approx. Weight (Kg) :48.6 / 55 Kg
• Dimension LxWxH (mm) : 607x460x610  mm
• Battery Specification :12 Volt 9 Ah

Description :

General Purpose Portable Generator, suitable for household, offices, Nursing Homes & Restaurants, Banks & ATMs, Field Jobs etc.
