Special Highlight :1.8 KVA Genset with simple & rugged design having low Noise, Low maintenance & long life. Gives Regulated and Stable Power.
Application :General purpose use for homes, shops, commercial use or field jobs for light loads applications
Generator
Max AC. Output : VA2000
Rated AC. Output : VA1625
Rated Current Amps :7.1
NFB Amps :8.5
AC. Output Voltage :225 Volts ± 10 Volt, 50 Hz, Single Phase
Alternator
Alternator Max :Current Capacity10 Amps.
Model : HM170P
Type : OHV25°Inclined,single cylinder, 4 strokes, S.I, Forced air cooling
Maximum Power :6.5 HP @ 3600
Bore x Stroke : 70×58 mm
Displacement :223 cc
Starting System :Recoil Start+Self Start
Engine
Fuel :Petrol + LPG (Optional)
Fuel Tank Capacity :Petrol -20.5 Ltr
Fuel Consumption at rated Load : Petrol 0.95 ltr/hr,LPG: 600gm./hr
Lube. Oil Capacity : 600 ml
Lubricating Oil Consumption :2.5 gm./Hr.Continues Running (With One Filling)22 Hrs
Sound level : (Db) (from 1 meter)<72Db
Voltmeter : Analogue
Digital Hour Meter : Optional
Oil Alert System : Yes
LPG/ Gas Fuel Compatibility :Yes
Panel &Other Standard Features
AMF Panel Auto & Remote Start Compatibility :Optional
Fuel Level Gauge :Yes
Overload Protection (NFB) : Yes
Costar Wheels : Yes
Size & Weight
Dimension LxWxH (mm)780 mm X 520 mm X 610 battery Specification12 Volt 9 Ah Size =135×75×140 (L×W×H)
Gross weight-KG (With Battery) :62 KG (Recoil Start) / 67 KG (Self Start)
Description: 1.8 KVA Genset with simple & rugged design having low Noise, Low maintenance & long life. Gives Regulated and Stable Power. General purpose use for homes, shops, commercial use or field jobs for light loads applications
